Coil Roofing Nails

Coil roofing nails are spirally shaped as a whole, and a plurality of linoleum nails are bound by iron wires and arranged side by side.

Specification

Diameter: 3.05mm (0.120")

Length: 19mm ~ 45mm (3/4" to 1 3/4")

Angle Degree: 15 or 16

Type of coil: conical-coiled; flat-coiled

Material: Q195/Q235 steel, aluminum, copper

Surface treatment: polished, galvanized, vinyl coated

Shank: smooth shank, ring shank, fluted shank

Packing: 120pieces/coil, 60 coils/carton, 48 cartons/pallet , 24 pallets in one 200 feet container

Product Advantages

1. Coil roofing nails have a full round head and are electro-galvanized to resist rust. Designed for use with most 15° coil roofing nailers.

2. Full round head electro galvanized smooth shank high wire collated roofing nails.

3. Nail provides excellent holding power for installation of asphalt roofing shingles and insulation boards.

4. High quality standards prevent jamming allowing you to work faster.

5. Electrogalvanized finish helps resist corrosion and rust.

Solutions to failures in use of coil roofing nails

In the process of using coil roofing nails, nail jams often occur. We can analyze the reasons and solve them from several aspects.

1. Curved due to abrasion of the nailing surface of the firing pin. Then immediately replace with a new firing pin assembly

2. The nail caps are small and thin due to the non-standard coil nail caps. Then check whether the size of the coil nail matches the nail gun or change the coil nail test

3. Because there is no corresponding length and adjustment nail plate degree when installing nails. Re-correspond to the length of the coiled nails, adjust the scale on the nail groove degree or check whether the coiled nails are jammed

4. Due to the low air pressure, the firing pin did not completely return to the gun nozzle. Then check whether the pressure of the air compressor is normal, and the normal pressure is 6-8kg. Whether the air pipe is too long (more than 20m), and whether the air pipe is too thin, causing the flow of the air source to be too low. It is recommended to use 8*12 specification air pipe.

5. The nail gun is short of oil or there is debris in the nailing tray, and the nails cannot be delivered normally. Then unplug the air source, add a suitable amount of lubricating oil from the air inlet, and then connect the air source for a few air tests or open the nail tray to check whether the O-ring inside is normal and clean.

Our Service

1. Strict control

We will strictly control raw materials and production processes to ensure that products meet the standards.

2. Rapid production

We have advanced production equipment and abundant production and operation to deliver goods as quickly as possible.

3. Rapid delivery

The factory is close to the port and supports rail and air transportation.

Hebei Cucheng Trading Co., Ltd. is a professional nails supplier in China. Nails products include common nails, roofing nails, concrete nails, screw nails, kinds of strip nails and staples etc. Welcome to contact us for 1 to 1 consulting exclusive consultant.
